Main Unit

Machine Type

Colour Laser Multifunctional

Core functions

Print, Copy, Scan, Send, Store and Optional Fax

Processor

Canon Dual Custom Processor (Shared)

Control Panel

5 inch TFT LCD WVGA Colour Touch panel

Memory

Standard: 2.0GB RAM

Interface Connection

NETWORK

Standard: 1000Base-T / 100Base-TX / 10Base-T, Wireless LAN (IEEE 802.11 b/g/n);

Optional: NFC

OTHERS

Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1;

Optional: Copy Control Interface

Paper Capacity (A4, 80/m²)

Standard:

1,200 Sheets

Maximum:

2,300 Sheets

Paper Source (A4, 80/m²)

Standard:

Two 550-sheet paper cassettes
100-sheets Multi Purpose Tray

Optional:

Dual 550-sheet paper cassettes (CASSETTE FEEDING UNIT-AP1)

Maximum:

2,300 Sheets

Paper output capacity (A4, 80/m²)

Standard:

250 Sheets

With Inner Finisher:

600 sheets *INNER FINISHER-K1

Finishing capabilities

Standard:

Collate, Group

With Inner Finisher:

Collate, Group, Offset, Staple, Staple-Free Staple, Staple-on-Demand

Supported media sizes

Cassette 1:

Standard size: A4, B5, A5R

Envelopes: ISO-C5

Custom Size: 139.7 x 182mm to 297 x 215.9mm

Cassette 2:

Standard size: A3, B4, A4, B5, A4R, A5R

Envelopes: No.10 (COM10), Monarch, DL

Custom Size: 139.7 x 182mm to 304.8 x 457.2mm

Cassete 3/4 (CASSETTE FEEDING UNIT-AP1):

Standard size: A3, B4, A4, A4R, B5R, B5, A5R

Custom Size: 139.7 x 182mm to 304.8 x 457.2mm

Multi-purpose tray:

Standard size: A3, B4, A4, A4R, B5R, B5, A5, A5R, SRA3

Custom size: 98.4 x 139.7mm to 320 x 457.2mm

Envelopes: No.10 (COM10), Monarch, ISO-C5, DL

Supported Media Weights

Cassette 1,2:

52 to 220g/m²

Cassette Feeding Unit:

52 to 220g/m²

Multi-purpose tray:

Coated paper: 52 to 256g/m²

Heavy Paper: 52 to 300g/m²

Duplex:

52 to 220g/m²

Warm-up Time

From Power On:

30 Seconds or Less

From Sleep Mode:

10 Seconds or Less

Dimensions (W x D x H)

DADF-AV1:

565 x 664 x 880mm

PLATEN COVER TYPE W:

565 x 635 x 777mm

Installation Space(W x D)

Basic:

978 x 1,117mm (when attach with DADF-AV1 + Multi-purpose tray extension extended + Cassette open)
978 x 1,088mm (imageRUNNER C3020 + Multi-purpose tray extension extended + Cassette open)

Fully Configured:

1,110 x 1,117mm ?when attach with imageRUNNER C3020 + INNER FINISHER-K1 + Multi-purpose tray extension extended + Cassette open?

Weight

Approx. 69.8kg including toner (when attach with DADF-AV1)

Toner (Estimated Yield @ 5% Coverage)

Black: 36,000
Colour: 19,000

Drum Yield

54,000

Print Specifications

Printing method

Colour Laser Beam Printing

Print Speed (BW/CL)

20ppm (A4), 15ppm (A3)

Print Resolution

600 x 600dpi, 1200 x 1200dpi

Page description languages

UFR II ?Standard?, PCL 6, Adobe PS3 (Option)

Double Sided Printing

Automatic (Standard)

Direct Print

Direct printing available from USB memory key
Supported file types: TIFF, JPEG, PDF and XPS.

Fonts

PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Barcode fonts*

PS fonts: 136 Roman
^{*Require optional BARCODE PRINTING KIT-D1}

Operating System

UFRII:

Windows Vista / Server 2008 / Windows 7 / Server 2008 R2 / Windows 8 / Server 2012 / Windows 8.1 / Server 2012 R2 / Windows 10 / Server 2016, MAC OS X (10.7.5 or later), Linux

PCL:

Windows Vista / Server 2008 / Windows 7 / Server 2008 R2 / Windows 8 / Server 2012 / Windows 8.1 / Server 2012 R2 / Windows 10 / Server 2016

PS:

Windows Vista / Server 2008 / Windows 7 / Server 2008 R2 / Windows 8 / Server 2012 / Windows 8.1 / Server 2012 R2 / Windows 10 / Server 2016, MAC OS X (10.7.5 or later)

PPD:

MAC OS 9.1 or later, MAC OS X (10.3.9 or later), Windows Vista / Windows 7 / Windows 8 / Windows10

Copy Specifications

Copy Speed (BW/CL)

20ppm (A4), 15ppm (A3)

First-Copy-Out Time (BW/CL)

Approx. 5.9 / 8.2 seconds or less

Copy resolution

Reading:

600 x 600dpi

Multiple Copies

Up to 999 copies

Copy Exposure

Automatic or Manual (11 Levels)

Magnification

25 - 400% (1% Increments)

Scan Specifications

Type

Colour Platen and Duplexing Automatic Document Feeder

Supported media size/s

DADF-AV1:

A3, B4, A4R, A4, B5R, B5, A5R, A5, B6

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows Vista / 7 / 8 / 8.1 / 10

Scan Resolution

300 x 300dpi, 600 x 600dpi

Scan Method

Send, Scan to USB, Pull scanning

Document Feeder Paper Capacity

DADF-AV1:

100 Sheets (80g/m²)

Double sided scanning

2-sided to 2-sided (Automatic)

Send Specifications

Destination

E-mail / Internet FAX (SMTP), SMB, FTP, Super G3 FAX(Optional)

Colour Mode

Auto Colour Select (Full Colour, Grayscale),
Auto Colour Select (Full Colour/ Black-and-White)
Full Colour, Grayscale, and Black-and-White

Address Book

LDAP (5) / Local (300) / One-touch (281)

Send resolution

300 x 300dpi

Communication protocol

File: FTP, SMB v3.0

E-mail / I-Fax: SMTP, POP3, I-Fax (Simple)

File Format

Standard: TIFF, JPEG, PDF(Compact, Searchable)

Optional: PDF(Encrypted, Digital Signature)

Fax Specifications

Optional / Standard

Optional on all models

Maximum Number of Connection Lines

1

Modem Speed

Super G3: 33.6kbps
G3: 14.4kbps

Compression Method

MH, MR, MMR, JBIG

Resolution

400 x 400dpi, 200 x 400dpi, 200 x 200dpi, 200 x 100dpi

Sending / Recording Size

A5* and A5R* to A3

^{*Sent as A4}

FAX memory

Up to 512 pages

Speed dials

Max. 281

Group dials

Max. 299 dials

Security Specifications

Authentication

Standard: Department ID Authentication, uniFLOW connectivity

Environmental Specifications

Operating Environment

Temperature:

10 to 30°C (50 to 86°F)

Humidity:

20 to 80% RH (no condensation)

Power source

220 - 240V (±10%), 50 / 60Hz (±2Hz), 4.0 Amp

Power consumption

Maximum:

Approx. 1.5kW

Standby:

Approx. 33.6W*

^{* Reference Value}

Sleep mode:

Approx. 2W (Wireless LAN power save mode:OFF), 1W (Wireless LAN power save mode:ON)
